Thermomixers

6 to 24 kW - High-precision thermal mixing

Thermal mixing systems for precise temperature control through the proportional combination of hot and cold water. Ideal for processes that require fine and rapid temperature adjustment without the need for a dedicated refrigeration system.

Thermomixers

Main Features

Accuracy of ±0.5°C
Temperature range: up to 120°C (water) or 250°C (oil)
Powers from 6 to 24 kW
3-way mixing valve
Motorized proportional actuator
Digital PID controller
PT100 temperature sensor
High pressure and flow pump
Stainless steel connections
Pressure gauges and thermometers
Y-filter at the inlet
Bypass for maintenance

Technical Specifications by Model

Complete line of HTMR thermomixers with powers from 6 to 24 kW. All models have a microprocessor PID control and can operate with water or thermal oil.

Model HTMR 06 kW

Heating

Power:6 kW
Max. Temp. (Water):120°C
Max. Temp. (Oil):250°C
Accuracy:±0,5°C

Hydraulics

Pump Flow:1,70 m³/h
Pump Pressure:2,5 bar
Reservoir Volume:12 L
Fluid:Water or Oil

Electrical Data

Voltage:3F (220/380/440 VCA) + N + T/60Hz
Installed Power:6,5 kVA
Current (220/380/440V):17,1 A / 9,9 A / 8,5 A

Control

Type:Microprocessed PID
Accuracy:±0,5°C

Structure

Dimensions (WxDxH):450 x 720 x 750 mm
Weight:55 Kg
Connections:3/4" Inlet/Outlet

Fluid

Water or Oil

Control

PID

Exchanger

Plates

Standards

NR10 e NR12

Benefits

Economy

Uses existing hot and cold water, without a compressor.

Fast Response

Instant temperature adjustment by mixing.

Simplicity

Reliable mechanical system with low maintenance.

Precision

Proportional control for stable temperature.

Applications

Washing processes
Textile industry
Food industry
Dyeing processes
Industrial baths
Rinsing systems
Pasteurization processes
Reactor control
